Vectra Hive S1
Autonomous Air Defense for Your Backyard
Vectra Hive S1
Autonomous Air Defense for Your Backyard
Executive Summary
The Vectra Hive S1 is a fully autonomous 'drone-in-a-box' system designed to neutralize mosquitoes within a 100-foot perimeter of the home. Utilizing a base station 'Hive' for heavy computational processing and charging, the system deploys a swarm of four ultra-compact nano-drones equipped with miniaturized high-voltage grids to intercept and eliminate pests. This chemical-free solution offers 24/7 protection by leveraging swarm logic to patrol, track, and zap mosquitoes, returning automatically to their dedicated docking bays on the Hive to recharge.
Technical Specifications
| Drone Form Factor | 1.2-inch propeller nano-quadcopter (approx. 65mm diagonal wheelbase) |
| Flight Time | 5-7 minutes per sortie (continuous rotation with 4 drones) |
| Kill Mechanism | Front-mounted 1.5kV nano-static discharge grid (0.2g payload) |
| Navigation | Optical Flow + SLAM (Simultaneous Localization and Mapping) via ESP32-S3 AI |
| Detection Range | Base station LiDAR: 30m radius; Onboard IR Camera: 3m precision tracking |
| Charging System | 4x Dedicated Magnetic Docking Ports on Hive (0-100% in 15 mins) |
| Connectivity | ESP-NOW (Low Latency) for Drone-to-Hive comms; WiFi 6 for App control |
Manufacturing Analysis
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Nano-Drone Flight Controller | ESP32-S3 SoC with AI Acceleration (AIO Board) | $4.50 |
| Propulsion System (x4 per drone) | 0702 25000KV Brushless Motors + 31mm Polycarbonate Props | $14.00 |
| Vision Sensor | OV3660 IR Night-Vision Camera Module (Stripped/Naked) | $6.00 |
| High Voltage Zapper Circuit | Micro-Flyback Transformer + SMD Capacitor Bank (1.5kV output) | $2.50 |
| Drone Battery | 1S 300mAh High-Voltage LiPo (LiHV) with BT2.0 connector | $3.50 |
| Hive Base Station Processor | Quad-core ARM Cortex-A72 (e.g., Raspberry Pi CM4 equivalent) | $35.00 |
| Hive Enclosure & Docking Bays | Injection Molded ABS + 4x Magnetic Pogo-pin Arrays | $30.00 |
