Sentinel IV Deployment Pod
Instant Infrastructure for the Unreachable.
Sentinel IV Deployment Pod
Instant Infrastructure for the Unreachable.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: g53p0w8q8
RENDER
Executive Summary
The Sentinel IV is a rapid-deployment, self-contained forward operating base designed for heavy-lift drone delivery. Encased in a hybrid carbon-fiber and chromoly steel exoskeleton, it survives 3G impact loads while housing two electric reconnaissance motorcycles, tactical weaponry, and life-support systems. Upon landing, the unit self-levels via hydraulic legs and opens into a fully illuminated, elevated command center.
Technical Specifications
| Dimensions (Closed) | 2.4m (L) x 1.8m (W) x 1.8m (H) |
| Dry Weight / Loaded Weight | 420 kg / 850 kg |
| Structural Composition | 3k Twill Carbon Fiber Shell over 4130 Chromoly Steel Cage |
| Vehicle Payload | 2x Modified Light Electric Enduro Motorcycles (72V system) |
| Deployment System | Drogue-stabilized parachute + Honeycomb crush-core base |
| Power System | 5kWh LiFePO4 Buffer Battery + 400W Deployable Solar Array |
| Lighting | Internal 4000K CRI 95 LED strips + Exterior floodlights |
Manufacturing Analysis
Complexity
High
Timeline
14 Months (R&D to First Production Unit)
Est. Tooling Cost
$150,000 - $200,000 (Large composite molds)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Composite Shell Panels | Pre-preg Carbon Fiber / Nomex Core | $6,500 |
| Exoskeleton Frame | 4130 Chromoly Steel (Welded/Powder-coated) | $2,800 |
| Electric Motorcycles (x2) | Aluminum Frame / Lithium Battery / Brushless Motor | $14,000 |
| Hydraulic Leveling Legs (x4) | Steel / Hydraulic Fluid / Servo Motors | $3,200 |
| Tactical Loadout (Rifles/Bow) | Composite / Steel / Optics | $5,500 |
| Interior Organization System | CNC Machined EVA Foam / Aluminum Extrusions | $2,100 |
| Impact Attenuation Base | Aluminum Honeycomb / Rubberized Polymer | $1,500 |
Est. Unit Cost$45,000 - $55,000
IntensityBalanced
