Executive Summary
The ResQ-1 Sprint is a decentralized rapid-response drone network designed to deliver a proprietary, ultra-lightweight mechanical CPR and AED unit to any coordinate in New York City within 60 seconds. Utilizing a grid of 150+ autonomous 'SkyDock' rooftop stations, the system bridges the critical gap between cardiac arrest onset and ambulance arrival, potentially increasing survival rates from <10% to over 50%. The drone features a custom carbon-fiber automated chest compression device that integrates directly into the airframe to minimize weight.
Technical Specifications
| Service Radius (Per Node) | 1.2 miles (1.9 km) to ensure <60s arrival |
| Max Airspeed | 85 mph (136 km/h) |
| Payload Weight | 5.2 kg (Includes 'Nano-Piston' CPR Device + AED) |
| Guidance System | LIDAR + RTK GPS + 5G Cellular Triangulation |
| Deployment Latency | <5 seconds from 911 trigger to launch |
| CPR Mechanism | Automated circumferential thoracic band (Load-distributing) |
Manufacturing Analysis
Complexity
High
Timeline
18-24 months (R&D, FAA Certification, Network Installation)
Est. Tooling Cost
$2.5M - $4M (Custom molds for aero-chassis and medical device integration)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Airframe Chassis | Toray T700 Carbon Fiber Monocoque | $450.00 |
| Propulsion System (x4) | High-KV Brushless Motors + 18-inch Carbon Props | $320.00 |
| CPR Actuator Module | High-Torque Servo / Tensile Dyneema Band | $850.00 |
| Integrated AED Core | Capacitor Bank / ECG Sensor Array | $600.00 |
| Battery Pack | Solid-State Lithium Metal (High Discharge) | $250.00 |
| Avionics & AI Core | NVIDIA Jetson Orin Module + Flight Controller | $550.00 |
Est. Unit Cost$3,200 - $4,500 (at scale)
IntensityBalanced
