ResQ-1 'Campus Guardian'
The 60-second heartbeat of school safety.
ResQ-1 'Campus Guardian'
The 60-second heartbeat of school safety.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: mdms79vhp
RENDER
Executive Summary
The ResQ-1 Campus Guardian is a decentralized, autonomous aerial response system specifically engineered for educational institutions and their immediate 1-mile radius. By miniaturizing mechanical CPR technology into a proprietary 2.8kg carbon-fiber 'LifeBand' unit and integrating the ultra-compact CellAED, this system delivers full Advanced Life Support (ALS) capability in under 60 seconds. The network transforms schools into community lifesaving hubs, bypassing traffic to stabilize cardiac arrest victims before ambulances arrive.
Technical Specifications
| Operational Radius | 1.0 mile (1.6 km) Geofenced Sprint Zone |
| Max Airspeed | 72 mph (115 km/h) for <60s arrival |
| Payload Capacity | 4.0 kg (Rated), 3.2 kg (Operational Load) |
| CPR Mechanism | Proprietary 'LifeBand' Pneumatic Piston (100 compressions/min) |
| Defibrillator | Integrated CellAED® (Single-cycle, voice-guided) |
| Propulsion | Hexacopter X6 Configuration with fully shrouded safety rotors |
| Station Type | Solar-assisted 'Hive' roof enclosure with climate control |
Manufacturing Analysis
Complexity
High
Timeline
14-18 months (Includes FAA Type Certification & Medical Device Class II clearance)
Est. Tooling Cost
$180,000 - $250,000 (Injection molds for shrouds & CPR chassis)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Airframe (Shrouded) | Molded Carbon Fiber / Polycarbonate Composite | $450.00 |
| Propulsion System (6x Motors + ESCs) | T-Motor High-Efficiency Brushless | $580.00 |
| Flight Controller & Avionics | Cube Orange+ with RTK GPS & LTE Module | $650.00 |
| LifeBand CPR Mechanism | Machined Aluminum / Pneumatic Actuators / Nylon Webbing | $1,200.00 |
| Integrated AED Unit | OEM CellAED Core | $300.00 |
| LiPo Battery Pack | 6S 22000mAh High Discharge | $280.00 |
Est. Unit Cost$3,500 - $4,200 (at 1000 unit volume)
IntensityBalanced
