PhotonEdge Atom
Micro-Scale Precision. Macro-Scale Power.
PhotonEdge Atom
Micro-Scale Precision. Macro-Scale Power.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: cpoajk3xy
RENDER
Executive Summary
The PhotonEdge Atom miniaturizes the SAK-Pro concept into a keychain-compatible form factor (60% volume reduction) without sacrificing core utility. By optimizing the laser output to a thermally manageable 1W and utilizing a unibody titanium monocoque chassis, the Atom delivers emergency cutting and signaling capabilities in a device that disappears into a coin pocket.
Technical Specifications
| Laser Diode | 1W 450nm Blue Solid State (Compact Emitter) |
| Dimensions | 62mm x 22mm x 14mm |
| Weight | 58g |
| Battery | 380mAh High-Discharge Li-Po (20C) |
| Chassis Construction | Grade 5 Titanium Monocoque with Copper Heat Spreader |
| Blade | 45mm Non-locking Slipjoint, M390 Steel |
| Safety | Capacitive Touch Sequence + Recessed Physical Switch |
| Runtime | 8 minutes continuous laser use / 30 days standby |
Manufacturing Analysis
Complexity
High
Timeline
6-8 Months
Est. Tooling Cost
45,000 USD
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| 1W Blue Laser Diode (PLT5 Series) | Semiconductor/Can Package | 18.00 USD |
| Unibody Chassis | Grade 5 Titanium Billet | 22.00 USD |
| Internal Heatsink | C11000 Copper | 4.50 USD |
| Micro-Blade | M390 Stainless Steel | 12.00 USD |
| Control PCB + Sensors | FR4 High TG | 8.50 USD |
| Li-Po Cell (Custom Form) | Lithium Polymer | 6.00 USD |
Est. Unit Cost85.00 USD
IntensityBalanced
