LumaFlow H2O
Hydration illuminated.
LumaFlow H2O
Hydration illuminated.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: gwz2xe5kh
RENDER
Executive Summary
The LumaFlow H2O is a vacuum-insulated smart water bottle designed to seamlessly integrate hydration habits into a user's daily workflow through intuitive visual cues. By housing all electronics within a hermetically sealed, dishwasher-safe lid, the design minimizes manufacturing complexity while maximizing durability and hygiene. It features a capacitive liquid level sensor and a 3-axis accelerometer to track intake with >95% accuracy, syncing via Bluetooth LE to a companion app for personalized hydration goals.
Technical Specifications
| Bottle Material | Double-wall vacuum insulated 304 (18/8) food-grade stainless steel |
| Capacity | 24 oz (710 ml) |
| Connectivity | Bluetooth 5.0 Low Energy (BLE) via Nordic nRF52832 SoC |
| Sensors | STMicroelectronics LIS3DH 3-axis accelerometer, Non-contact capacitive liquid level sensor |
| Lighting | 12-LED RGB Ring (WS2812B) with diffusive light pipe |
| Battery | 350mAh Lithium Polymer, 14-day life, custom magnetic pogo-pin charging |
| Water Resistance | IPX7 (Lid), Dishwasher safe (Bottle body) |
Manufacturing Analysis
Complexity
Medium
Timeline
6-8 months (Design lock to T1 samples: 3 months; Certification & Pilot Run: 3 months)
Est. Tooling Cost
$28,000 - $35,000 (Includes steel molds for bottle hydroforming, multi-cavity injection molds for lid, and overmolding tools for seals)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Vacuum Insulated Bottle Body | 304 Stainless Steel, Powder Coated | $4.50 |
| Smart Lid Housing (Top & Bottom) | Injection Molded BPA-Free Tritan & ABS | $1.20 |
| Main PCB Assembly | FR4, BLE SoC, Accelerometer, Charge Controller | $3.80 |
| LED Ring Module | 12x WS2812B LEDs on Flex PCB | $0.95 |
| Capacitive Sensor Strip | Copper foil on Flex PCB | $0.60 |
| Battery | 3.7V 350mAh Li-Po | $1.10 |
| Charging Cable | USB-A to Custom Magnetic Pogo Pin | $1.35 |
| Packaging | Recycled Cardboard Box + Pulp Tray | $0.85 |
Est. Unit Cost$14.35 - $16.50 (at 5,000 unit volume)
IntensityBalanced
