Helios-X Tactical Survival Staff
Cut Through The Darkness.
Helios-X Tactical Survival Staff
Cut Through The Darkness.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: 6bj92gp2a
RENDER
Executive Summary
A high-performance telescopic trekking pole integrating a 2000-lumen floodlight and a focused 3W Class 4 laser emitter for emergency cutting and fire starting. Engineered with a proprietary active cooling handle and aerospace-grade carbon fiber, this tool bridges the gap between mobility aid and extreme survival utility.
Technical Specifications
| Extended Length | 135cm (53 inches) |
| Collapsed Length | 64cm (25 inches) |
| Laser Output | 3000mW (3W) 445nm Blue Diode (Class 4) |
| Illumination | CREE XHP70.2 LED, 2000 Lumens |
| Power Source | Integrated 2x 21700 Li-Ion Cells (10,000mAh) |
| Thermal Management | Copper Core Passive Heatsink with Graphite Spreader |
Manufacturing Analysis
Complexity
High
Timeline
14-18 Months
Est. Tooling Cost
$85,000 USD
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Telescopic Shaft Segments | 3K Twill Weave Carbon Fiber | 22.00 |
| Laser Diode Module & Driver | Nichia NUBM44 Diode / Copper Housing | 45.00 |
| Grip & Housing | Glass-Filled Nylon / TPE Overmold | 12.50 |
| Battery System | Lithium Ion Cells + BMS PCB | 18.00 |
| Locking Mechanisms | Anodized Aluminum 7075 | 8.50 |
Est. Unit Cost$145.00 USD
