Cuprum Aegis Shell
The Faraday Cage You Wear.
Cuprum Aegis Shell
The Faraday Cage You Wear.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: ozu4ndfw7
RENDER
Executive Summary
The Cuprum Aegis Shell is a high-performance technical garment designed to shield the wearer from 99.9% of electromagnetic frequencies (EMF) and radio frequency (RF) radiation. Utilizing a proprietary copper-nickel infused polyester mesh integrated into a breathable, weather-resistant outer chassis, this jacket functions as a flexible Faraday cage without compromising comfort or style. It targets privacy-conscious urban commuters, tech workers, and health-focused individuals seeking protection in high-density signal environments.
Technical Specifications
| Shielding Effectiveness | >85 dB attenuation (10MHz - 10GHz) |
| Conductive Material | Copper-Nickel infused polyester mesh (Surface resistance <0.05 Ohm/sq) |
| Closure System | Dual-layer conductive storm flap with silver-plated magnetic seals |
| Frequency Block | 5G, Wi-Fi, Bluetooth, RFID, Cellular (4G/LTE) |
| Breathability | RET < 12 (Highly Breathable) via micro-perforated outer shell |
Manufacturing Analysis
Complexity
High
Timeline
4-6 months (Prototyping to First Batch)
Est. Tooling Cost
$12,000 - $15,000 (Pattern grading, conductive seam sealing molds)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Shielding Core Fabric | Copper/Nickel conductive polyester mesh (2 layers) | $28.00 |
| Outer Shell | Translucent Ripstop Nylon (Copper-tinted) | $12.50 |
| Inner Lining | Hypoallergenic Bamboo-Cotton blend (Skin contact safe) | $8.00 |
| Conductive Closure | Silver-coated conductive zipper tape + Magnetic strip inserts | $15.00 |
| Grounding Hardware | Optional snap-stud for external ground wire attachment | $1.50 |
Est. Unit Cost$85.00 - $110.00 (at 1,000 unit volume)
IntensityBalanced
