Executive Summary
The AeroDrop Vanguard is a ruggedized, drone-deployable supply pod designed for rapid aerial delivery of critical adventure and survival gear. Utilizing a hybrid construction of a rotomolded LLDPE outer shell and an expanded polypropylene (EPP) shock-absorbing core, the pod ensures payload integrity upon impact. This view reveals the clamshell interior organization, where a modular webbing system secures the payload within the shock-absorbing foam core, bridging the gap between military airdrop logistics and civilian adventure support.
Technical Specifications
| Dimensions | 600mm x 400mm x 350mm (approx. 24 x 16 x 14 inches) |
| Empty Weight | 4.2 kg (9.2 lbs) |
| Max Payload Capacity | 20 kg (44 lbs) |
| Internal Volume | 45 Liters (Modular Compartments) |
| Lid Opening Angle | 110 degrees with friction-hinge retention |
| Water Resistance | IP67 (Sealed via silicone gasket) |
Manufacturing Analysis
Complexity
Medium
Timeline
4-6 Months (Design to T1 Samples)
Est. Tooling Cost
$25,000 - $35,000 USD (Combined Rotomold & EPP Molds)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Outer Shell | Rotomolded Linear Low-Density Polyethylene (LLDPE) | $45.00 |
| Internal Impact Core | Molded Expanded Polypropylene (EPP) Foam (45g/l density) | $18.00 |
| Recovery System | 20kg Class Ballistic Parachute (Nylon 6.6) + Servo Release | $330.00 |
| Retention System | Neon Nylon Webbing, Fidlock Magnetic Buckles | $22.00 |
| Adventure Loadout (Base) | Shelter (Bivy), Water Filtration, First Aid, Comms Beacon | $150.00 |
Est. Unit Cost$565.00 USD (Fully loaded with chute & basic gear)
