Executive Summary
The Aegis Loop Air is a next-generation wearable airbag system designed to replace traditional bicycle helmets for urban commuters. Utilizing a proprietary 'Crash-Sense' algorithm processed by a high-frequency 6-axis IMU, the device detects accident dynamics and deploys a helium-filled ripstop nylon hood in 0.1 seconds. This solution offers 8x superior shock absorption compared to EPS foam while maintaining a discreet, scarf-like aesthetic that addresses the 'vanity barrier' to helmet adoption.
Technical Specifications
| Deployment Time | 0.1 seconds (100ms) |
| Sensor Array | Bosch BMI270 6-Axis IMU (2000Hz sampling) |
| Shock Absorption | 150g max peak acceleration (vs. ~250g for EPS helmets) |
| Battery Life | 16 hours active cycling (USB-C Fast Charge) |
| Weight | 780g (1.7 lbs) |
| Water Resistance | IP67 (Collar Electronics) |
Manufacturing Analysis
Complexity
High
Timeline
14-18 Months (DVT to MP)
Est. Tooling Cost
$180,000 - $250,000 (Injection Molds + RF Welding Dies)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Hybrid Micro-Inflator | Cold Gas Helium Cylinder with Pyrotechnic Trigger | $18.50 |
| Airbag Bladder | Ultra-High Tenacity Nylon 6.6 Ripstop (Silicone Coated) | $12.00 |
| Main Logic Board | 4-Layer Flexible PCB (Polyimide) with MCU & IMU | $22.00 |
| Outer Collar Shell | TPU-Coated Spandex / Injection Molded ABS Skeleton | $14.50 |
| Power Cell | Lithium-Polymer Battery (3.7V, 2000mAh) | $4.50 |
| Fasteners & Harness | Fidlock Magnetic Buckle & Nylon Webbing | $6.00 |
Est. Unit Cost$85 - $110 USD
IntensityBalanced
