Monolith FX-1000
Print Your World. Industrial Furniture Manufacturing at Studio Scale.
Monolith FX-1000
Print Your World. Industrial Furniture Manufacturing at Studio Scale.
TECHNICAL DOCUMENTATION • GENERATED BY CONJUREANYTHING • ID: vqv6kmyvj
RENDER
Executive Summary
The Monolith FX-1000 is a large-format, pellet-fed 3D printer designed to bridge the gap between industrial manufacturing and bespoke furniture design. By utilizing a high-flow pellet extrusion system, it reduces material costs by up to 90% compared to filament-based printers while offering a massive 1.2m³ build volume. Engineered for designers and micro-factories, it enables the rapid production of full-scale chairs, tables, and architectural elements in hours, not days.
Technical Specifications
| Build Volume | 1200mm (X) x 1200mm (Y) x 1200mm (Z) |
| Extrusion System | Direct-Drive Screw Pellet Extruder (High-Torque) |
| Max Flow Rate | 500g/hour (approx. 400mm³/s) |
| Nozzle Diameter Options | 1.0mm, 2.0mm, 3.0mm, 5.0mm (Quick-Swap) |
| Motion System | X/Y Rack & Pinion Drive, Z Ball Screw (4-point independent leveling) |
| Max Travel Speed | 300mm/s |
| Bed Temperature | Up to 120°C (Multi-zone Silicone Mains Heater) |
| Chamber Temperature | Active Heating up to 70°C |
| Controller | Duet 3 Mainboard 6HC + SBC (Raspberry Pi 5) |
| Power Requirement | 220V-240V Single Phase, 30A |
Manufacturing Analysis
Complexity
High
Timeline
12-16 Months (Prototype to MP)
Est. Tooling Cost
$45,000 (Custom extrusion dies, bed casting molds, injection molded cover parts)
Bill of Materials
| Component | Material | Cost |
|---|---|---|
| Frame Structure | 8080 & 4080 Heavy-Duty Aluminum Extrusion (Black Anodized) | $1,800 |
| Pellet Extruder Head | Custom Screw Assembly with NEMA 23 Planetary Gearbox | $2,500 |
| Motion Motors | 4x NEMA 34 Closed-Loop Stepper Motors (High Torque) | $600 |
| Linear Motion | Hiwin 20mm Linear Rails + Helical Rack & Pinion Gears | $1,200 |
| Control Electronics | Duet 3 6HC Mainboard + Expansion Board + 7" Touchscreen | $450 |
| Heated Bed System | 15mm Cast Aluminum Tool Plate + 4-Zone Silicone Heater (3000W) | $1,100 |
| Enclosure Panels | Double-walled Polycarbonate with Aluminum Composite Frame | $850 |
| Pellet Hopper & Dryer | 5kg Capacity Active Drying Hopper System | $400 |
Est. Unit Cost$9,500 - $11,000 USD
IntensityBalanced
